14310513101160 | Harting
PCB connector, 5 pole, pitch 2.54 mm, straight, white, 14310513101160
Order No.: 42F8789
EAN: 5713140206267
MPN:
14310513101160
har-flexicon 2,54 FPV-5 WH
Series: HAR-FLEXICON
Unit Price (€ / pc.)
1.8802 € *
Standard delivery time from the manufacturer is: On Request
PCB connector, 14310513101160, Harting
The 14310513101160 is a vertical PCB connector with push-in-spring-cage termination and liquid crystal polymer material.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.54 mm | |
| contact surface | silver-plated | |
| Connection | push-in spring connection | |
| Rated voltage | 160 V | |
| Orientation | straight | |
| Number of rows | 1 | |
| Pin number | 5 pole | |
| Additional parts | equipped | |
| Colour | white | |
| Rated current | 6 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | VN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
