14121014005000 | Harting
PCB connector, 10 pole, pitch 3.5 mm, black, 14121014005000
Unit Price (€ / pc.)
3.6057 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
3.61 € *
Price list
Quantity
Price per unit*
1 pcs.
3.6057 €
10 pcs.
3.2844 €
50 pcs.
2.9869 €
100 pcs.
2.6894 €
*incl. VAT plus shipping costs
Subject to prior sale
Header, 14121014005000, Harting
Header, Vertical, Reflow soldering termination (THR), Rated current: 11 A, Contacts: 10, Copper alloy, Sn over Ni Mating side, Sn over Ni Termination side, PCB fixing: With thread flange, Polyamide (PA), Polyphthalamide (PPA), Black.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 3.5 mm | |
| contact surface | tin-plated | |
| Contact type | pin | |
| Connection | PCB connection | |
| Connection plating | tin-plated | |
| Rated voltage | 150 V | |
| Number of rows | 1 | |
| Pin number | 10 pole | |
| Colour | black | |
| Version | pin header | |
| Rated current | 11 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
