14011213102333 | Harting
PCB connector, 12 pole, pitch 2.54 mm, black, 14011213102333
Unit Price (€ / pc.)
8.7584 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
8.76 € *
Price list
Quantity
Price per unit*
1 pcs.
8.7584 €
10 pcs.
8.0563 €
50 pcs.
7.4137 €
100 pcs.
6.8187 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal block, 14011213102333, Harting
PCB terminal block, Horizontal, Push-in-spring-cage termination, Reflow soldering termination (SMT), Rated current: 6 A, Contacts: 12, Copper alloy, Sn over Ni Mating side, Sn over Ni Termination side, Liquid crystal polymer (LCP), Black.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | print terminal | |
| Pin number | 12 pole | |
| Grid | 2.54 mm | |
| Connection | push-in spring connection | |
| contact surface | tin-plated | |
| Connection plating | tin-plated | |
| Rated voltage | 160 V | |
| Rated current | 6 A | |
| Number of rows | 1 | |
| Colour | black |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
