09170169622 | Harting
Pin header, 16 pole, pitch 1.27 mm, straight, beige, 09170169622
Unit Price (€ / pc.)
6.9139 € *
Available: 13 pcs.
Total Price:
6.91 € *
Price list
Quantity
Price per unit*
1 pcs.
6.9139 €
10 pcs.
6.0690 €
100 pcs.
5.3431 €
250 pcs.
5.1408 €
1000 pcs.
4.7957 €
*incl. VAT plus shipping costs
Subject to prior sale
Insulation displacement connectors for IC socket series SEK 17, type Harting 0917.
For solder mounting on PCBs or insertion in IC socket; Grid: 2.54 mm. Operating current: 1.0 A. Test voltage: 500 V. Insulation resistance: min. 10 Gohm. Contact resistance: max. 20 mohm. Insulator material: thermoplastic mold (PC), UL 94 V-0. Contacts: tinned. Connections: 0.45 x 0.35 mm solder pins for 0.8 mm holes. Can be connected to ribbon cables with 1.27 mm grid (AWG 26/7 to AWG 28/7). Operating temperatures: –40 to +125 °C.
Technical attributes (type, number of poles, dimensions A/C/D): 09170169622, 16–pole, A 23/C 11/D 7.62 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 1.27 mm | |
| Orientation | straight | |
| Connection | IDC connection | |
| Contact type | pin | |
| Rated current | 1 A | |
| Additional parts | equipped | |
| Version | pin header | |
| Pin number | 16 pole | |
| contact surface | tin-plated | |
| Number of rows | 2 | |
| Colour | beige |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
