09033322921 | Harting

Male connector, type C, 32 pole, a-b-c, pitch 2.54 mm, solder pin, straight, 09033322921

Order No.: 44F544
EAN: 4099891016531
MPN:
09033322921
09 03 332 2921
Series: DIN 41612
09033322921 Harting DIN PCB Connectors
Image may differ
Unit Price (€ / pc.)
4.2007 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
4.20 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
4.2007 €

Male connector, 09033322921, Harting

Male connector, Wave soldering termination, Rated current: ‌2 A, Contacts: 32, Angled, Copper alloy, Noble metal over Ni Mating side, Sn over Ni Termination side, Performance level: 1, acc. to IEC 60603-2, Coding: Coding with loss of contacts, PCB fixing: With fixing flange, With snap-in clip, Thermoplastic resin, glass-fibre filled, RAL 7032 (pebble grey)

Technical specifications
Rated current 2 A
Grid 2.54 mm
Pin number 32 pole
Design C
Orientation straight
Connection solder pin
Contact type pin
Contact row assignment a-b-c
Performance level 1
Logistics
Country of origin DE
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
