09670095604 | Harting
D-Sub plug, 9 pole, standard, equipped, straight, solder cup, 09670095604
Unit Price (€ / pc.)
5.5811 € *
Available: 83 pcs.
Total Price:
5.58 € *
Price list
Quantity
Price per unit*
1 pcs.
5.5811 €
10 pcs.
4.9266 €
100 pcs.
4.2959 €
250 pcs.
4.1412 €
*incl. VAT plus shipping costs
Subject to prior sale
Male Header, 09670095604, Harting
Connector, solder cup connection, rated current: 7.5 A, pin, size: D-Sub 1, thermoplastic moulding material, glass fibre reinforced (PBTP), steel, surface treated, white, contacts: 9, conductor cross-section: 0.5 mm² max, copper alloy, gold plated, connection side, gold plated, plug side
Technical Data
- Assembly: Cable connection
- Pin number: 9-pole
- Type of locking: Through-hole
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact connection | solder cup | |
| Performance level | 3 | |
| Assembly | straight | |
| Pole image | standard | |
| Attachment (rear panel) | through hole | |
| Additional parts | equipped | |
| Grid | 2.54 mm | |
| Pin number | 9 pole | |
| Version | pin header | |
| Type of locking | through hole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
