09662527615 | Harting

D-Sub socket, 15 pole, standard, angled, solder pin, 09662527615

Order No.: 42P3725
EAN: 5713140221154
MPN:
09662527615
09 66 252 7615
Series: D-Sub
09662527615 Harting D-Sub Connectors
Image may differ
Unit Price (€ / pc.)
4.7243 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
4.72 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
4.7243 €

D-Sub connector, 09662527615, Harting

Connector, wave soldering termination, Rated current: 6.5 A, female, size: D-Sub 2, thermoplastic resin, glass-fibre filled (PBTP), Shell: steel, plated steel, black, Contacts: 15 with grounding pin, copper alloy, noble metal over Ni.

Technical specifications
Filter Property Value
Grid 2.74 mm
Version socket header
Attachment (rear panel) through hole
Pin number 15 pole
Pole image standard
Contact connection solder pin
Assembly angled
Performance level 3
Type of locking threaded insert M3
Logistics
Property Value
Customs tariff number 85366990
Country of origin RO
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free No
