09654616713 | Harting

D-Sub plug, 37 pole, standard, equipped, straight, solder pin, 09654616713

Order No.: 44F5992
EAN: 4099889794038
MPN:
09654616713
09 65 461 6713
Series: D-Sub
09654616713 Harting D-Sub Connectors
Image may differ
Unit Price (€ / pc.)
7.6755 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
7.68 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
7.6755 €

D-Sub plug, 09654616713, HARTING

This D-sub connector is an industry standard for cable-to-board connectivity applications and also can be universally used as a device interface.

Features

  • Material flammability class acc. to UL 94: V-0
  • Contact material: Copper alloy
  • Shell material: Plated steel
Technical specifications
Type of locking threaded bolts 4-40 UNC
Pole image standard
Attachment (rear panel) through hole
Assembly straight
Grid 2.76 mm
Contact connection solder pin
Pin number 37 pole
Version pin header
Additional parts equipped
Performance level 2
Logistics
Country of origin CH
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
