09565617713 | Harting

D-Sub plug, 78 pole, high density, equipped, straight, solder pin, 09565617713

Order No.: 44F5366
EAN: 4099889789911
MPN:
09565617713
09 56 561 7713
Series: D-Sub
09565617713 Harting D-Sub Connectors
Image may differ
Unit Price (€ / pc.)
10.9956 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
11.00 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
10.9956 €

D-Sub plug, 09565617713, HARTING

This D-sub connector is an industry standard for cable-to-board connectivity applications and also can be universally used as a device interface.

Features

  • Material flammability class acc. to UL 94: V-0
  • Shell material: Steel, nickel-plated
  • Contact material: Copper alloy
  • Performance level: 3

Applications

  • For data transmission
  • For signal applications
  • For power applications
Technical specifications
Type of locking threaded bolts 4-40 UNC
Pole image high density
Attachment (rear panel) through hole
Assembly straight
Grid 2.41 mm
Contact connection solder pin
Pin number 78 pole
Version pin header
Additional parts equipped
Performance level 3
Logistics
Country of origin CN
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
