09562617713 | Harting

D-Sub plug, 26 pole, high density, equipped, straight, solder pin, 09562617713

Order No.: 44F5290
EAN: 4099889789201
MPN:
09562617713
09 56 261 7713
Series: D-Sub
09562617713 Harting D-Sub Connectors
Image may differ
Unit Price (€ / pc.)
4.2602 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
4.26 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
4.2602 €

D-Sub plug, 09562617713, HARTING

This D-sub connector is an industry standard for cable-to-board connectivity applications and also can be universally used as a device interface.

Features

  • Material flammability class acc. to UL 94: V-0
  • Shell material: Steel, nickel-plated
  • Contact material: Copper alloy
  • Performance level: 3

Applications

  • For data transmission
  • For signal applications
  • For power applications
Technical specifications
Type of locking threaded bolts 4-40 UNC
Pole image high density
Attachment (rear panel) through hole
Assembly straight
Grid 2.29 mm
Contact connection solder pin
Pin number 26 pole
Version pin header
Additional parts equipped
Performance level 3
Logistics
Country of origin CN
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
