09552666820741 | Harting
D-Sub plug, 15 pole, standard, equipped, angled, solder pin, 09552666820741
Unit Price (€ / pc.)
7.0686 € *
Available: 52 pcs.
Total Price:
7.07 € *
Price list
Quantity
Price per unit*
1 pcs.
7.0686 €
3 pcs.
6.8306 €
10 pcs.
6.6045 €
20 pcs.
6.4617 €
40 pcs.
6.3308 €
*incl. VAT plus shipping costs
Subject to prior sale
D-Sub plug, 09552666820741, HARTING
This D-sub connector is an industry standard for cable-to-board connectivity applications and also can be universally used as a device interface.
Features
- Material flammability class acc. to UL 94: V-0
- Shell material: Nickel-plated
- Contact material: Phosphorus bronze
- Performance level: 2
Applications
- For data transmission
- For signal applications
- For power applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.76 mm | |
| Contact connection | solder pin | |
| Attachment (rear panel) | through hole | |
| Performance level | 2 | |
| Pole image | standard | |
| Assembly | angled | |
| Type of locking | threaded bolts 4-40 UNC | |
| Pin number | 15 pole | |
| Additional parts | equipped | |
| Version | pin header |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Reel with 160 pieces |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
