09150006206 | Harting
Receptacle, 2.5 mm², AWG 14, crimp connection, silver-plated, 09150006206
Unit Price (€ / pc.)
1.2971 € *
Available: 108 pcs.
Total Price:
1.30 € *
Price list
Quantity
Price per unit*
1 pcs.
1.2971 €
250 pcs.
1.1305 €
1000 pcs.
0.9877 €
2500 pcs.
0.9044 €
*incl. VAT plus shipping costs
Subject to prior sale
Crimp contact for Han DD/Han D/Han 8 U/Han K/Han Q 7 inserts, type 0915000.
For insertion in the contact inserts for Han D, Han DD and Han 8/U, HAN Q 7, as well as control contact for the Han K series, for crimp terminals.
Female contact, type 0915000.
Technical attributes (type, conductor cross-sections, silver-plated or gold-plated finish): 6206, 2.5 mm², silver–plated
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 14 | |
| Contact material | copper alloy | |
| Contact connection | crimp connection | |
| contact surface | silver-plated | |
| Version | receptacle | |
| Cable cross-section | 2.5 mm² | |
| Insulation diameter | 3.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
