19000007104 | Harting
Cable gland, M25, 33 mm, Clamping range 9 to 16 mm, IP68, black, 19000007104
Order No.: 44F9325
EAN: 4099891200626
MPN:
19000007104
19 00 000 7104
Unit Price (€ / pc.)
5.5692 € *
Standard delivery time from the manufacturer is: 2 Weeks
Cable gland, 19000007104, HARTING
Cable gland, M25, Clamping range: 9-16 mm, Material (cable glands): Polyamide, IP68, Wrench size: 33.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Degree of protection (IP) | IP68 | |
| max. clamping range | 16 mm | |
| Product type | cable gland | |
| min. operating temperature | -40 °C | |
| Material | PA | |
| spanner size | 33 mm | |
| max. operating temperature | 100 °C | |
| min. clamping range | 9 mm | |
| Thread size | M25 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol |
| SVHC free | No |
| RoHS conform | Yes |
