GPS-1830D | GW Instek
Laboratory power supply, 18 VDC, outputs: 1 (3 A), 0 to 3 A, 54 W, 100-240 VAC, GPS-1830D
Unit Price (€ / pc.)
238.00 € *
Standard delivery time from the manufacturer is: 1 Week
Mains adapter, GPS-1830D, GW Instek
GW Instek GPS-1830D 54W Single-Output Linear DC Power Supply with Digital LED Screen, 18V DC, 3 Amp. The GPS-Series are single output, 54 to 90W, linear DC power supplies. The GPS-Series include both analog and digital display meters with varying power outputs. The GPS-Series feature Overload and reverse polarity protection as well as high regulation and low ripple / noise that are maintained at 0.01% and < 1mVrms, respectively. Continuous or dynamic internal load selection accommodates applications such as pulsed current. Remote control terminals offer programming and operation from an external device.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Range of Output Currence | 0 to 3 A | |
| Depth | 285 mm | |
| Output voltage DC | 18 VDC | |
| Output current | 3 A | |
| Width | 128 mm | |
| Height | 145 mm | |
| Power | 54 W | |
| Number of outputs | 1 | |
| Input voltage AC | 100-240 VAC |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
