RSNTRA08GNTB | GREATECS
DIP switche, 8 pole, straight, 25 mA/24 VDC, RSNTRA08GNTB
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
1.1424 € *
Available: 27 pcs.
Total Price:
1.14 € *
Price list
Quantity
Price per unit*
1 pcs.
1.1424 €
23 pcs.
1.0829 €
69 pcs.
1.0115 €
253 pcs.
0.9163 €
1012 pcs.
0.8092 €
*incl. VAT plus shipping costs
Subject to prior sale
DIP switch, RSNTRA08GNTB, GREATECS
This switch is slide switch of one body type that each pole is parallel and it is constituted by one moving contact and two terminals. The terminal plating by gold gives excellent results when soldering.
Features
- Low contact resistance
- High reliability
- Self-clean on contact area
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | DIP switche | |
| Pin number | 8 pole | |
| Actuation | on top | |
| Design | straight | |
| Connection | PCB pin | |
| contact surface | gold-plated | |
| Grid | 2.54 mm | |
| Breaking capacity | 25 mA/24 VDC |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bar with 23 pieces |
| Customs tariff number | 85365019 |
| Country of origin | JP |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
