SSP 32N 32RU 18P | Gossen Metrawatt

Laboratory power supply, 32 VDC, outputs: 1 (18 A), 0 to 18 A, 320 W, 230 VAC, SSP 32N 32RU 18P

Order No.: 21K5253

EAN: 4016138540949

MPN:

SSP 32N 32RU 18P

KONSTANTER SSP 320-32

SSP 32N 32RU 18P Gossen Metrawatt Bench Power Supplies and Loads Image 2

SSP 32N 32RU 18P Gossen Metrawatt Bench Power Supplies and Loads Image 3

Image may differ

Key Specification:

Output voltage DC 32 VDC

Output current 18 A

Range of Output Currence 0 to 18 A

Download Datasheet Technical specifications

This item is no longer available.

As an alternative, we recommend the following item:

Laboratory power supply, 35 VDC, outputs: 1 (14.5 A), 0 to 14.5 A, 500 W, 115-230 VAC, LABKON P500 35V 14.5A

Order No.: 21K5234

Manufacturer: Gossen Metrawatt

per pc. 1,785.00 € *

Go to product

*incl. VAT plus shipping costs

Description

SSP Constant, K334A, Gossen Metrawatt

The SSP 32N series KONSTANTERs cover the ratings of 120W, 240W, 320 W with an output voltage up to 80 V and a rated current up to 20A.

BET (Bidirectional Energy Transformation) circuitry realizes nearly load-independent rise and fall times. The devices have analog as well as digital interfaces and are therefore ideally suited for use in the test field. Power outputs at the front and rear allow use as a laboratory or as a built-in device.

Features

Load-independent setpoint jumps < 1ms
Auto-Range Output
Short-time working range up to 200% of rated output power

Technical specifications

Filter	Property	Value
	Output voltage DC	32 VDC
	Output current	18 A
	Range of Output Currence	0 to 18 A
	Power	320 W
	Input voltage AC	230 VAC
	efficiency	69 %
	Number of outputs	1
	Width	221.5 mm
	Height	88 mm
	Depth	400 mm
