LSP 32 K 36 R 3 | Gossen Metrawatt
Laboratory power supply, 0 bis 36 VDC, outputs: 1 (3 A), 0 to 3 A, 100 W, 115-230 VAC, LSP 32 K 36 R 3
Unit Price (€ / pc.)
1,249.50 € *
Available in 7 Days: 17 pcs. - if ordered today
Laboratory power supply, K111A, Gossen Metrawatt
The laboratory power supplies of the LSP-Konstanter 32K series are high-precision DC power supplies for use in research, development, production, service and training. Three types are available with an output power of approx. 100 W.
The devices are characterized by high control accuracy and very low residual ripple with high ease of operation.
Features
- Potential free output
- Safe electrical isolation
- Output switchable ON/OFF
- Voltage and current control (rectangular characteristic)
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Width | 215 mm | |
| Depth | 280 mm | |
| Output voltage DC | 0 to 36 VDC | |
| Output current | 3 A | |
| Power | 100 W | |
| Input voltage AC | 115-230 VAC | |
| Range of Output Currence | 0 to 3 A | |
| Height | 100 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85044083 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
