N 51422 | GMW

Panel measuring device, rotary iron measuring device, class 2.5, 4 A, GMW N 51422

Order No.: 19K423
EAN: 4099891453701
MPN:
N 51422
RKN85 4,0A
Series: RkN85
N 51422 GMW Current Meter Image 1
N 51422 GMW Current Meter Image 2
Image may differ
Unit Price (€ / pc.)
177.31 € *
Standard delivery time from the manufacturer is: 5 Weeks
Total Price:
177.31 € *
Price list
Quantity
Price per unit*
1 pcs.
177.31 €
3 pcs.
165.41 €
6 pcs.
153.51 €
*incl. VAT plus shipping costs
Subject to prior sale

Display instruments, type GMW RKN 85.

Class 2.5 moving iron instrument. For DC and AC current/voltage; Mounting position: 90° vertical. Pointer travel: 90°. Scale length: 52 mm. Bezel: gray.

Type: 4.0 A

Technical specifications
Filter Property Value
Connection screw connection
Width 85 mm
Max. current 4 A
Assembly front panel mounting
Version rotary iron measuring device, class 2.5
AC or DC measurement possible AC/DC
Product type panel measuring device
Height 69 mm
Logistics
Property Value
Country of origin CZ
Customs tariff number 90303370
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
