45420 00000B | GMW
Panel measuring device, moving coil meter, 20 mA, GMW 45420 00000B
Unit Price (€ / pc.)
43.8396 € *
Standard delivery time from the manufacturer is: 1 Week
Display instruments, type GMW DQB 45H.
Moving-coil mechanism, for DC and AC voltage, rail mount, spring-loaded needle bearing; Tolerance class: 1.5. Housing: polycarbonate (UL 94 V-0). Degree of protection: IP 52. Front dimensions: 45 x 45 mm. Scale length: 42 mm. Housing dimensions: 45 x 87.2 x 65 mm.
Technical attributes (type, measuring range, scale): 45420, 0/4 to 20 mA, 0 to 100 %
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Max. current | 20 mA | |
| AC or DC measurement possible | AC/DC | |
| Connection | screw connection | |
| Product type | panel measuring device | |
| Height | 45 mm | |
| Min. current | 0 mA | |
| Assembly | DIN rail | |
| Width | 87.2 mm | |
| Installation depth | 65 mm | |
| Version | moving coil meter |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 90303900 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
