SZ47035025040 | FTcap
Electrolytic capacitor, 47 µF, 350 V (DC), -10/+30 %, can, Ø 25 mm, SZ47035025040
Unit Price (€ / pc.)
12.2570 € *
Available: 234 pcs.
Total Price:
12.26 € *
Price list
Quantity
Price per unit*
1 pcs.
12.2570 €
10 pcs.
11.1741 €
50 pcs.
10.4363 €
100 pcs.
9.8413 €
250 pcs.
9.3772 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in aluminum can, Standard
With M 18 x 1.5 bushing mount
Capacitance: 2x47 µF
Rated voltage: 350 VDC
minus pole at case
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Ripple current | 500 mA | |
| Rated voltage (DC) | 350 V | |
| Connection | soldering lug | |
| Tolerance | -10/+30 % | |
| Design | can | |
| diameter | 25 mm | |
| ESR (Equivalent Series Resistance) | 1.27 Ω | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -40 °C | |
| Version | polar | |
| Length | 40 mm | |
| Capacity | 47 µF |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
