K-AGU353 | Frolyt
Bipolar electrolytic capacitor, 4.7 µF, 63 V (DC), ±10 %, axial, Ø 8.5 mm, K-AGU353
Order No.: 12D767
MPN:
K-AGU353
EAGU 4,7µF/63V 8,5x20,0 mm ±10% K-AGU353
Unit Price (€ / pc.)
1.3923 € *
Available: 800 pcs.
Total Price:
1.39 € *
Price list
Quantity
Price per unit*
1 pcs.
1.3923 €
10 pcs.
0.9877 €
100 pcs.
0.8449 €
500 pcs.
0.7497 €
3600 pcs.
0.6783 €
45000 pcs.
0.5236 €
*incl. VAT plus shipping costs
Subject to prior sale
Aluminum electrolytic capacitors, K-AGU353, Frolyt
Aluminium electrolytic capacitor, low-voltage, axial, miniaturized, insulated, non-polarized, switching-proof, service life min. 1,500h to 2,500h at +105°C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Ripple current | 50 mA | |
| Rated voltage (DC) | 63 V | |
| Tolerance | ±10 % | |
| Design | axial | |
| diameter | 8.5 mm | |
| ESR (Equivalent Series Resistance) | 30.48 Ω | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -40 °C | |
| Version | bipolar | |
| Length | 16 mm | |
| Capacity | 4.7 µF |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
