E-RSM301 | Frolyt
Electrolytic capacitor, 470 µF, 10 V (DC), ±20 %, SMD, pitch 4.5 mm, Ø 10.2 mm, E-RSM301
Unit Price (€ / pc.)
0.8211 € *
Available: 698 pcs.
Total Price:
8.21 € *
Price list
Quantity
Price per unit*
10 pcs.
0.8211 €
50 pcs.
0.7259 €
250 pcs.
0.6307 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD aluminum electrolytic capacitor, type Frolyt ERSM.
For surface mounting, suitable for use at temperatures up to +105 °C to DIN IEC 60384-1
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 10 V | |
| Tolerance | ±20 % | |
| Design | SMD | |
| diameter | 10.2 mm | |
| ESR (Equivalent Series Resistance) | 810 mΩ | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -55 °C | |
| Version | polar | |
| Length | 10 mm | |
| Capacity | 470 µF | |
| Grid | 4.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
