E-RS3079 | Frolyt
Electrolytic capacitor, 22 µF, 100 V (DC), ±20 %, SMD, pitch 4.5 mm, Ø 8.9 mm, E-RS3079
Unit Price (€ / pc.)
1.4042 € *
Available: 1,022 pcs.
Total Price:
1.40 € *
Price list
Quantity
Price per unit*
1 pcs.
1.4042 €
10 pcs.
0.8806 €
50 pcs.
0.7735 €
250 pcs.
0.6664 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD aluminum electrolytic capacitor, type Frolyt ERS.
For surface mounting and high soldering heat load, suitable for use at temperatures of up to +105 °C. Compliant with DIN IEC 60384-18 (without quality confirmation). Capacitance tolerance ±20 %
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ESR (Equivalent Series Resistance) | 5.78 Ω | |
| Length | 12 mm | |
| max. operating temperature | 105 °C | |
| Version | polar | |
| diameter | 8.9 mm | |
| Capacity | 22 µF | |
| Rated voltage (DC) | 100 V | |
| Tolerance | ±20 % | |
| min. operating temperature | -55 °C | |
| Grid | 4.5 mm | |
| Design | SMD |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
