E-KSU009 | Frolyt

Bipolar electrolytic capacitor, 100 µF, 16 V (DC), ±20 %, radial, pitch 5 mm, Ø 8.7 mm, E-KSU009

Order No.: 12D714
EAN: 4099879871817
MPN:
E-KSU009
E-KSU009 100/16 8,7X12,7
Series: EKSU
E-KSU009 Frolyt Electrolytic Capacitors Image 1
E-KSU009 Frolyt Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
0.7021 € *
Available: 1,387 pcs.
Total Price:
0.70 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7021 €
10 pcs.
0.4998 €
100 pcs.
0.4284 €
500 pcs.
0.3808 €
1000 pcs.
0.3451 €
*incl. VAT plus shipping costs
Subject to prior sale

Bipolar electrolytic capacitor, E-KSU009, Frolyt

Aluminum electrolytic capacitor

Features

  • Low-voltage-electrolytic capacitor
  • Small dimensions
  • Insulated/Non polarized
  • Pulse-proof
  • Service life 1000...2500 h/+105 °C
Technical specifications
Filter Property Value
min. operating temperature -40 °C
Grid 5 mm
Tolerance ±20 %
Version bipolar
Rated voltage (DC) 16 V
max. operating temperature 105 °C
Capacity 100 µF
Length 12.7 mm
diameter 8.7 mm
ESR (Equivalent Series Resistance) 3.18 Ω
Design radial
Logistics
Property Value
Customs tariff number 85322200
Country of origin DE
Compliance
Property Value
SVHC free No
Date of RoHS guidelines 3/31/15
RoHS conform Yes
Substance description Lead
