1 5020 730 012 | Flexa
Straight hose screw fitting, M12, 14 mm, PP, IP54, gray, (L) 43 mm, 1 5020 730 012
Unit Price (€ / pc.)
5.1884 € *
Available: 30 pcs.
Total Price:
5.19 € *
Price list
Quantity
Price per unit*
1 pcs.
5.1884 €
10 pcs.
4.8433 €
50 pcs.
4.4982 €
100 pcs.
4.3316 €
*incl. VAT plus shipping costs
Subject to prior sale
Corresponding plastic fittings series USK-M and USK-P, type 5020.
With outer thread and faces for hexagonal wrench; Connecting thread: metric to EN 60423, or Pg to DIN 40430. Optimal protection against the ingress of dust and liquids. High vibration resistance and tensile strength. Material case and inner bushing: polypropylene (PP). Seal ring: TPE. Degree of protection: IP 65. Operating temperatures: –10 to +110 °C.
With metric thread, series USK-M, type 5020.
Technical attributes (type, connecting thread, conduit outer diameter (OD). Dimension B. Dimension L): 5020.730.012, M 12 x 1.5, OD 14, B 25, L 43 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Thread size | M12 | |
| Nominal width | 14 mm | |
| Material | PP | |
| Colour | gray | |
| Length | 43 mm | |
| Degree of protection (IP) | IP54 | |
| min. operating temperature | -10 °C | |
| max. operating temperature | 110 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 39174000 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
