10007156 | Fischer Elektronik
Thermal joint film, 1.43 W/mK, silicone, (L x W) 200 x 200 mm, 10007156
Unit Price (€ / pc.)
48.2188 € *
Available: 16 pcs.
Next delivery: 48 pcs. on 2025-09-16
Total Price:
48.22 € *
Price list
Quantity
Price per unit*
1 pcs.
48.2188 €
5 pcs.
45.3271 €
15 pcs.
43.5778 €
50 pcs.
41.6619 €
150 pcs.
39.9245 €
*incl. VAT plus shipping costs
Subject to prior sale
Silicon sections for heat dissipation, type Fischer Bqu.
Sections starting at 200 x 200 mm, glass fiber-reinforced silicon-foil, 0.2 mm thickness; Color: brown. Material hardness: 89 Shore A. Dielectric strength: 6.0 kV. Insulation resistance: 1.0 x 10^6 ohm/cm. Thermal conductivity: 1.43 W/mK. Thermal resistance: 0.16 K/W. Operating temperatures: –60 to +180 °C. Elongation: max. 2.0 %. Inflammability to UL 94 V-0.
Type: Bqu, heat dissipation section
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Thermal conductivity | 1.43 W/mK | |
| Thermal resistense | 0.16 K/W | |
| min. operating temperature | -60 °C | |
| max. operating temperature | 180 °C | |
| Material | silicone | |
| Thickness | 0.2 mm | |
| Length | 200 mm | |
| Width | 200 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85472000 |
| Country of origin | JP |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
