10031644 | Fischer Elektronik
DIL connector, 16 pole, pitch 2.54 mm, straight, black, 10031644
Unit Price (€ / pc.)
2.8917 € *
Next delivery: 40 pcs. on 2025-10-21
Total Price:
2.89 € *
Price list
Quantity
Price per unit*
1 pcs.
2.8917 €
25 pcs.
2.4395 €
100 pcs.
2.2610 €
250 pcs.
2.1420 €
1000 pcs.
1.9754 €
*incl. VAT plus shipping costs
Subject to prior sale
DiL plugs, type Fischer Dils.
2.54 mm grid, with spring bronze contacts, gold-plated on nickel primer; Current loading per contact: max. 1.0 A. Plug-in platform and housing: polysulphone. Dielectric strength: 1.0 kV.
Plug inserts, type Dils.
Technical attributes (number of poles, dimensions C/L/B): 16-pole, C 7.62/L 22.6/B 12.5 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection plating | tin-plated | |
| Connection | solder pin | |
| Colour | black | |
| Additional parts | equipped | |
| Pin number | 16 pole | |
| Contact type | socket/pin | |
| Orientation | straight | |
| Rated voltage | 150 V | |
| contact surface | gold-plated | |
| Version | DIL connector | |
| Rated current | 1.5 A | |
| Number of rows | 2 | |
| Grid | 2.54 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369095 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
