72.11.9.024.0000 | Finder
Monitoring relays, 1 Form C (NO/NC), 24 V (DC), 16 A, 400 V (AC), 72.11.9.024.0000
Order No.: 34G1428
EAN: 8012823302195
MPN:
72.11.9.024.0000
721190240000
Unit Price (€ / pc.)
53.7404 € *
Standard delivery time from the manufacturer is: 1 Week
Monitoring relay, 72.11.9.024.0000, Finder
Level control relay for conductive liquids, equipped with a fixed sensitivity of 150 kΩ, a fixed tripping delay of 1s, with filling or emptying function selectable via an external jumper link.
Features
- Filling and emptying functions
- LED indicator
Applications
- Industrial washing machines
- Swimming pools
- Control and management of water
- Bottling plant
- Milk processing plant
- Control panels for pumps
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact type | 1 Form C (NO/NC) | |
| switching current | 16 A | |
| Coil voltage (DC) | 24 V | |
| Switching Voltage (AC) | 400 V | |
| Breaking capacity | 4000 VA | |
| Connection | screw connection | |
| Contact material | AgNi |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 90261029 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
