7L.46.0.024.2200 | Finder

LED switch cabinet light, 9 W, 24 V, 1200 lm, 5000 K, 120°, 7L.46.0.024.2200

Order No.: 07N2465
EAN: 8012823433141
MPN:
7L.46.0.024.2200
7L4600242200
Series: 7L
7L.46.0.024.2200 Finder Luminaires and Light Fixtures
Image may differ
Unit Price (€ / pc.)
135.4220 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
135.42 € *
Price list
Quantity
Price per unit*
1 pcs.
135.4220 €
3 pcs.
131.3403 €
10 pcs.
126.8302 €
25 pcs.
123.4506 €
*incl. VAT plus shipping costs
Subject to prior sale

LED control cabinet light, 7L.46.0.024.2200, Finder

The LED panel light can be mounted anywhere in the control cabinet thanks to the direct magnetic mounting or screw-on metal clips. It emits a 5000 K cool white light with low power consumption and has a beam angle of 120°.

Features

  • 1200 lumens, 9 W
  • With movement detector
  • Plug-in terminals for the connection to a single or multiple units (up to 7 lamps)
Technical specifications
Colour transparent
Luminous flux 1200 lm
Degree of protection (IP) IP20
Width 46 mm
average nominal life 60000 h
Power 9 W
Length 310.6 mm
Version LED light
min. operating temperature -30 °C
max. operating temperature 55 °C
Radiation angle 120 °
Colour temperature 5000 K
Rated voltage 24 V
Logistics
Country of origin IT
Customs tariff number 85395200
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
