66.82.8.230.4000 | Finder
Relay, 2 Form C (NO/NC), 230 V (AC), 4000 Ω, 30 A, 440 V (AC), monostable, 66.82.8.230.4000
Order No.: 34G2175
EAN: 8012823447735
MPN:
66.82.8.230.4000
668282304000
Unit Price (€ / pc.)
18.0166 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
18.02 € *
Price list
Quantity
Price per unit*
1 pcs.
18.0166 €
5 pcs.
17.5525 €
10 pcs.
17.1122 €
*incl. VAT plus shipping costs
Subject to prior sale
Power relay, 66.82.8.230.4000, Finder
2 pole changeover (DPDT) 30 A power relay with 250 Faston connections and Flange mount.
Features
- Reinforced insulation between coil and contacts according to EN 60335-1; 8 mm creepage and clearance distances
Applications
- Power generators
- Industrial washing machines
- Burners, boilers and furnaces
- Industrial furnaces and ovens
- Air conditioners
- Hoists and cranes
- Back-up generators
- Industrial motors
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact type | 2 Form C (NO/NC) | |
| switching current | 30 A | |
| Coil voltage (AC) | 230 V | |
| Coil resistance | 4000 Ω | |
| Switching Voltage (AC) | 440 V | |
| Connection | plug-in connection | |
| Coil type | monostable | |
| Contact material | AgCdO |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | ES |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
