20.26.8.230.4000 | Finder

Current-surge relay, 2 Form A (N/O), 230 VAC, 16 A, 230 V, 400 W, 20.26.8.230.4000

Order No.: 34G1186
EAN: 8012823274515
MPN:
20.26.8.230.4000
202682304000
Series: 20
20.26.8.230.4000 Finder Impulse Switches and Dimmer
Image may differ
Unit Price (€ / pc.)
22.134 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
22.13 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
22.134 €

Impulse switch, 20.26.8.230.4000, Finder

Impulse switch for 35 mm rail, 2 NO contacts for 16 A / 250 V AC, contact material: AgSnO2, max. switching capacities at 230 V AC: AC1 4000 VA, AC15 750 VA, incandescent and halogen lamps 2000 W, fluorescent lamps compensated 750 W, fluorescent lamps uncompensated 1000 W, energy saving lamps 400 W, LED (230 V AC) 400 W, LV halogen lamps or LED with ECG 400 W, LV halogen lamps or LED with CCG 800 W. Coil data: 230 V AC, 6.5 VA, 2500 Ohm, width 17.5 mm, switching sequence: off off / on off / on on, test button and mechanical switch position indicator, relay protection class: IP 20

Features

  • 17.4 mm wide
  • Test button with mechanical indicators
  • AC coils and DC coils
  • Cadmium free contact material
Technical specifications
Filter Property Value
Size 67 x 23 x 92 mm
Lamp wattage 400 W
Assembly DIN rail
Rated current 16 A
Control Voltage 230 VAC
Rated voltage (AC) 230 V
Latching switching function 2 Form A (N/O)
Dimmable No
Logistics
Property Value
Country of origin IT
Customs tariff number 85364900
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
