22.44.0.230.4410 | Finder
Contactor, 4 pole, 40 A, 400 VAC, 4 Form B (N/C), coil 230 VAC, screw connection, 22.44.0.230.4410
Order No.: 34G1649
EAN: 8012823376370
MPN:
22.44.0.230.4410
224402304410
Unit Price (€ / pc.)
64.3314 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
64.33 € *
Price list
Quantity
Price per unit*
1 pcs.
64.3314 €
2 pcs.
61.7491 €
3 pcs.
59.3810 €
*incl. VAT plus shipping costs
Subject to prior sale
Modular contactor, 22.44.0.230.4410, Finder
Installation contactor for 35 mm rail, 4 NC contacts for 40 A / 440 V AC, contact material AgSnO2, max. Switching capacities at 230 V AC: AC1-AC-7a: 16 kVA, rated current AC3-AC7b 22 A, incandescent and halogen lamps 4000 W, fluorescent lamps with ECG 1500 W, fluorescent lamps uncompensated 1500 W, energy-saving lamps 1000 W, LED (230 V AC) 1000 W, LV halogen lamps or LED with ECG 1000 W, LV halogen lamps or LED with CCG 1500 W. Coil 230 V AC/DC, width 53.5 mm, mechanical switch position indicator, relay protection class: IP 20.
Features
- Coil and contacts rated for continuous service
- Protective separation between coil and contacts (reinforced insulation)
- Standard version with mechanical indicator
Applications
- Hotel room energy-enabling units
- Garden and night lighting
- Streetlights and car park lighting
- Bathroom lighting control
- Office lighting control
- Pump control
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | contactor | |
| Latching switching function | 4 Form B (N/C) | |
| Control Voltage | 230 VAC | |
| Assembly | DIN rail | |
| Rated current | 40 A | |
| Pin number | 4 pole | |
| Rated Voltage | 400 VAC | |
| Degree of protection (IP) | IP20 | |
| Connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | SI |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
