22.32.0.024.1520 | Finder
Contactor, 25 A, 1 Form A (N/O) + 1 Form B (N/C), coil 250 VAC, 22.32.0.024.1520
Unit Price (€ / pc.)
24.8829 € *
Standard delivery time from the manufacturer is: 1 Week
Installation contactor for 35 mm rail, 1 NO and 1 NC contact for 25 A / 250 V AC, contact material AgNi, max. switching capacities at 230 V AC: AC1 6250 VA, AC15 1800 VA, 1-phase motor load, AC3 (230 V AC) 1 kW, energy saving lamps 100 W, LED (230 V AC) 100 W, LV halogen lamps or LED with electronic ballast 100 W, LV halogen lamps or LED with electronic ballast 300 W. Coil: 24 V AC/DC, width 17.5 mm, with LED and mechanical switch position indicator, relay protection class: IP 20.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | contactor | |
| Latching switching function | 1 Form A (N/O) + 1 Form B (N/C) | |
| Rated current | 25 A | |
| Control Voltage | 250 VAC | |
| Assembly | DIN rail | |
| Degree of protection (IP) | IP20 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
