304-40064-02 | ept
Female connector, type C, 96 pole, a-b-c, pitch 2.54 mm, solder pin, straight, 304-40064-02
Order No.: 52F7054
EAN: 4099891021047
MPN:
304-40064-02
Unit Price (€ / pc.)
5.6882 € *
Available: 6 pcs.
Next delivery: 25 pcs. on 2025-10-30
Total Price:
5.69 € *
Price list
Quantity
Price per unit*
1 pcs.
5.6882 €
10 pcs.
5.2836 €
50 pcs.
4.8671 €
100 pcs.
4.4268 €
*incl. VAT plus shipping costs
Subject to prior sale
Female connector DIN 41612/IEC 60603-2, type ept.
Requirements class 2; Quality class to DIN EN 60603-2: II/400 insertion/removal cycles. Insulation resistance: min. 1000 Gohm. Spring contact: double, double spring, two-sided. Insulator: PBTP, glass fiber-reinforced (UL 94 V-0), PC, glass fiber-reinforced (UL 94 V-1). Operating temperatures: –55 to +125 °C (design H = –65 to +125 °C). Certifications: UL.
FeFemale connector C, straight, with solder pins.
Pin: 0.6 x 0.6 mm.
Technical attributes (type, number of poles, contact row assignments, overall length): 304-40064-02, 96-pole, a-b-c, 4.6 mm, 94.9 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.54 mm | |
| Orientation | straight | |
| Connection | solder pin | |
| Contact row assignment | a-b-c | |
| Contact type | socket | |
| Rated current | 1 A | |
| Design | C | |
| Performance level | 2 | |
| Pin number | 96 pole |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Original Packaging | Bar with 25 pieces |
| Customs tariff number | 85389099 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
