CMEYSX321SL | Epson
Crystal, 27.12 MHz, 12 pF, ±10 ppm, 40 Ω, SMD, CMEYSX321SL
Order No.: 77D9771
EAN: 4099879148735
MPN:
CMEYSX321SL
TSX-3225 27.120000 MHz 12.0 + 10.0 - 10.0
Unit Price (€ / pc.)
0.2761 € *
Standard delivery time from the manufacturer is: 16 Weeks
Total Price:
276.08 € *
Price list
Quantity
Price per unit*
1000 pcs.
0.2761 €
2000 pcs.
0.2547 €
3000 pcs.
0.2368 €
*incl. VAT plus shipping costs
Subject to prior sale
Applications: Mobile phone, Bluetooth, W-LAN, ISM band radio, Clock for MPU
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Frequency | 27.12 MHz | |
| Frequency stability | +/-10 | |
| Tolerance | ±10 ppm | |
| Load Capacity | 12 pF | |
| ESR (Equivalent Series Resistance) | 40 Ω | |
| Assembly | SMD | |
| Length | 3.2 mm | |
| Width | 2.5 mm | |
| Height | 0.6 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Number of connection pads | 4 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Original Packaging | Reel with 1,000 pieces |
| Customs tariff number | 85416000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
