E33-VT651-M01T | ELMA
Incremental encoder, 15 V, impulses 16, E33-VT651-M01T
Unit Price (€ / pc.)
13.3399 € *
Standard delivery time from the manufacturer is: 6 Weeks
Incremental encoder, E33-VT651-M01T, ELMA
High performance incremental encoder.
Features
- Rotational life: up to 1 million revolutions
- Gold plated contacts
- IP68 shaft and front panel sealing
- Robust metal housing
Applications
- Value and menu control for industrial PLCs
- Avionics, measurement and test equipment
- Frequency and channel selection for two way radios
- User interface controls for medical devices
- Volume and menu setting for transportation control and entertainment systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | incremental encoder | |
| Length | 26.9 mm | |
| Pulses per revolution | 16 | |
| Connection | solder pin | |
| Voltage | 15 V | |
| Assembly | through hole |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | RO |
| Customs tariff number | 85365015 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
