6643275-1 | ELCON
Pin header, 1 pole, pitch 2.54 mm, angled, black, 6643275-1
Unit Price (€ / pc.)
7.9135 € *
Available in 5 Days: 708 pcs. - if ordered today
Power connector, 6643275-1, ELCON
The 6643275-1 provides a reliable high current power interconnection with quick connect/disconnect function for space constrained motherboard-daughterboard, cableboard and board-busbar power delivery applications. This product use a multifingered spring which provides a greater surface contact area, thus ensuring small millivolt drop, minimum heat generation and very low insertion and extraction forces.
Features
- Uses high-performance crown contact
- True compliant press-fit and solder tails
- Pin locking feature option
- Meets safety regulatory requirements
- Parallel and perpendicular
Applications
- Power distribution
- Board-to-board interconnection
- High-density power designs
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Connection | press-fit | |
| Rated voltage | 250 V | |
| Orientation | angled | |
| contact surface | silver-plated | |
| Version | pin header | |
| Connection plating | silver-plated | |
| Pin number | 1 pole | |
| Contact type | pin | |
| Grid | 2.54 mm | |
| Rated current | 35 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
