LED2472T TI800 | ELC
Panel measuring device, 2 A, ELC LED2472T TI800
Unit Price (€ / pc.)
73.78 € *
Standard delivery time from the manufacturer is: 12 Weeks
Ampermeter, LED2472TTI800, ELC
Features
- Display : 31/2 red 14 mm LED indicators
- Limit of the measure in frequency (RMS mode) : 40 to 750 Hz
- The masses of measurement input (e-) and supply are connected except in case of using optional one of two supplies.
- Appearance : Indication of the presence of an alternating voltage. Two side clips for quick mounting without tools, on a surface having between 0.8 circumferential thickness and 5 mm.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | screw connection | |
| Width | 72 mm | |
| Height | 24 mm | |
| Assembly | DIN rail | |
| Max. current | 2 A | |
| Product type | panel measuring device | |
| AC or DC measurement possible | AC/DC |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 90303320 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
