FRNC-B network cable, Cat 7, 8-wire, AWG 26-7, green, MK7104.100GR
Order No.: 26P1332
EAN: 4049759151652
MPN:
MK7104.100GR
Unit Price (€ / pck.)
84.1330 € *
Available in 5 Days: 1 pck. - if ordered today
Network cable, MK7104.100GR, EFB Elektronik
The network cable MK7104 is constructed for transmissions up to 600 MHz and exceeds with the electrical transmission properties and requirements of the category 7. With this cable transmission rates up to 10 GBit according to IEEE 802.3 are possible.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 8 | |
| Halogen free | Yes | |
| Core insulation material | PE | |
| Drag chain suitable | No | |
| Cable material | copper, tin-plated | |
| Colour | green | |
| Outer diameter | 6.5 mm | |
| Version | network cable/raw cable | |
| Category | Cat 7 | |
| Temperature range (active) | -20 °C to 60 °C | |
| Temperature range (unmoved) | 0 °C to 60 °C | |
| AWG cross-section | AWG 26-7 | |
| Shielding | shielded | |
| Material | FRNC-B |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85444920 |
| Original Packaging | Ring with 100 meters |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
