99732.100 | EFB-Elektronik
LSZH sheathed line, Cat 7, 0.26 mm², AWG 23, black, 99732.100, package with 100 meters
Order No.: 26P2789
EAN: 8717511438773
MPN:
99732.100
NCNR (non cancelable / non returnable)
Unit Price (€ / pck.)
185.3782 € *
Standard delivery time from the manufacturer is: On Request
Installation cable, 99732.100, EFB Elektronik
The data cable is equipped with a halogen-free, flame-retardant and water-tight sheath and can therefore be used universally indoors and outdoors universally suitable for indoor and outdoor use (also for underground installation) and designed for transmissions up to 1000 MHz. Its electrical transmission properties exceed the requirements of category 6, 6A, 7. cabling lines of channel class E, EA, F according to ISO/IEC 11801 (AMD 2:2009) or EN 50173-1 (2009) are set up with this cable. Transmissions of 10 GBit according to IEEE 802.3 are possible with this cable.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | network cable | |
| Cable cross-section | 0.26 mm² | |
| AWG cross-section | AWG 23 | |
| Category | Cat 7 | |
| Colour | black | |
| Material | LSZH | |
| Cable material | copper, bright | |
| Core insulation material | PE | |
| Shielding | shielded | |
| Halogen free | Yes | |
| Drag chain suitable | No | |
| Temperature range (unmoved) | -20 °C to 60 °C | |
| Temperature range (active) | 0 °C to 50 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444920 |
| Original Packaging | Ring with 11.7 meters |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
