98704.100 | EFB-Elektronik
PVC network cable, Cat 5e, 8-wire, 0.16 mm², AWG 26-7, blue, 98704.100
Order No.: 26P1342
EAN: 4049759074104
MPN:
98704.100
Unit Price (€ / pck.)
188.0914 € *
Standard delivery time from the manufacturer is: On Request
Network cable, 98704.100, EFB Elektronik
The 98704.100 is a Cat. 5E Patch cable with the structure tuned to a fast and reliable packing! Electrically and mechanically high-quality 300 MHz patch cords - exceeds the highest expectations. It guarantees limits according to Cat.5: ISO / IEC 11801 and EN 50173-1, EN 50288-2-2. As data jumper cable in patch panels and as cord for the transmission of digital and analogue voice, image and data signals. It is especially suitable for all applications of class D.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Category | Cat 5e | |
| AWG cross-section | AWG 26-7 | |
| Core insulation material | PVC | |
| Temperature range (active) | -20 °C to 60 °C | |
| Colour | blue | |
| Halogen free | No | |
| Number of cores | 8 | |
| Shielding | shielded | |
| Outer diameter | 5.1 mm | |
| Temperature range (unmoved) | 0 °C to 50 °C | |
| Material | PVC | |
| Drag chain suitable | No | |
| Version | network cable | |
| Cable material | copper, tin-plated | |
| Cable cross-section | 0.16 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444210 |
| Original Packaging | Ring with 100 meters |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
