QG 030 - 198/12 | ebm-papst

DC-tangential blowers, 12 V, 100 m³/h, QG 030

Order No.: 88B9702
EAN: 4099889484823
MPN:
QG 030 - 198/12
9392715011
Series: QG 030
QG 030 - 198/12 ebm-papst Tangential Blowers, diagonal fans
Image may differ
Unit Price (€ / pc.)
116.977 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
116.98 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
116.977 €

DC tangential blower, QG 030 - 198/12, ebm-papst

The QG 030 - 198/12 is a tangential blower with high air flow rate, electronically commutated external rotor motor with ball bearing system and integrated electronic commutation system, polarity reversal/blockage and overload protection. Impeller bracket with friction bearing, impeller and fan housing made of aluminum, housing side parts made of plastic.

Technical specifications
Rated voltage 12 V
Width 260.4 mm
Height 47.5 mm
Depth 50 mm
Volume flow 100 m³/h
Sound pressure level 51 db
speed 4250 1/min
Type of bearing ball bearing
Logistics
Country of origin DE
Customs tariff number 84145925
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
