4182 NGX | ebm-papst
DC axial fan, 12 V, 119 x 119 x 38 mm, 160 m³/h, 44 dB, slide bearing, ebm-papst 4182 NGX
Unit Price (€ / pc.)
48.1474 € *
Standard delivery time from the manufacturer is: On Request
DC Axial fan, 4182 NGX, EBM-PAPST
The 4182 NGX axial fan is used in all industries where cooling of components or machinery is essential. Fan works by drawing air over a surface to cool it, or by pushing hot air away to cool it.
Features
- Very pressure stiff characteristic for high volume flow at high back pressure
- Low operating noise at high back pressure
- Electronic commutation completely integrated
- Protected against polarity reversal and blocking
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | DC axial fan | |
| Rated voltage | 12 V | |
| Width | 119 mm | |
| Height | 119 mm | |
| Depth | 38 mm | |
| Volume flow | 160 m³/h | |
| Sound pressure level | 44 db | |
| speed | 2800 1/min | |
| Type of bearing | slide bearing | |
| Power consumption | 3 W |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Customs tariff number | 84145925 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
