278479 | EATON
Motor protection switch, 3 pole, 0.63 to 1 A, 0.55 kW, 1 A, screw connection, 278479
Order No.: 82P0674
EAN: 4015082784799
MPN:
278479
PKZM01-1
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
81.1580 € *
Available: 1 pcs.
Total Price:
81.16 € *
Price list
Quantity
Price per unit*
1 pcs.
81.1580 €
3 pcs.
77.6475 €
5 pcs.
74.4226 €
*incl. VAT plus shipping costs
Subject to prior sale
Motor-protective circuit-breaker, 278479, EATON
A motor-protective circuit breaker rated for 440 V, with a power capacity of 0.55 kW, operates within a current range of 0.63 to 1 A and has an IP20 protection rating.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | motor protection switch | |
| Pin number | 3 pole | |
| Release | 0.63 to 1 A | |
| Engine power | 0.55 kW | |
| Rated current | 1 A | |
| Rated voltage | 440 V | |
| Actuator | pushbutton | |
| Network frequency | 50/60 Hz | |
| Connection | screw connection | |
| Assembly | DIN rail | |
| Degree of protection (IP) | IP20 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85362010 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead | Perfluorobutane sulfonic acid (PFBS) and its salts |
| SVHC free | No |
| RoHS conform | Yes |
