808-H-0,05A | E-T-A
Circuit breaker, magnetic, 1 pole, 0.05 A, 24 V (DC), solder connection, PCB mounting, IP30, 808-H-0,05A
Unit Price (€ / pc.)
45.7555 € *
Standard delivery time from the manufacturer is: 6 Weeks
Magnetic overcurrent circuit breaker, 808-H-0,05A, E-T-A
Single pole miniaturised magnetic circuit breaker with unique high-speed operating mechanism and push/pull on/off manual actuation. Fitted with electrically separate excitation and switching circuits, and one pair of auxiliary contacts which close when the main circuit is open. Also suitable for impulse operation. Designed for printed circuit board mounting. Low temperature sensitivity.
Applications
- Printed circuit boards and components
- Safety and control systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 24 V | |
| Degree of protection (IP) | IP30 | |
| Product type | circuit breaker | |
| Version | magnetic | |
| Rated current | 0.05 A | |
| Actuator | push button | |
| Pin number | 1 pole | |
| Connection | solder connection | |
| Type of mounting | PCB mounting |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85362010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
