0046619 | DOLD
Soft starter, 2 phase, 5.5 kW, 400 V (AC), 0046619
Order No.: 90P0117
EAN: 4030641466190
MPN:
0046619
IR9027
Unit Price (€ / pc.)
363.9258 € *
Standard delivery time from the manufacturer is: 2 Weeks
Softstarter, 0046619, DOLD
The 0046619 is a softstarter designed to enable 1-phase or 3-phase induction motors to start smoothly. This product slowly ramps up the current on two phases, therefore allowing the motor torque to build up slowly. This reduces the mechanical stress on the machine, prevents damage to conveyed material and limits the start current. When the motor is up to full speed the semiconductors in this is bridged to prevent internal power losses and heat build up.
Features
- Increases the life of squirrel cage motors and mechanical drives
- Easily fitted to existing installations
- Semiconductors are brigded after softstart
- Adjustable ramp time and starting torque
- LED indication
Applications
- Motor with gear, belt or chain drive
- Fans, pumps, compressors, conveyor systems
- Door drives, packaging machines
Technical specifications
| Filter | Property | Value |
|---|---|---|
| min. operating temperature | 0 °C | |
| Number of phases | 2 | |
| Version | soft start device | |
| Rated voltage (AC) | 400 V | |
| Power | 5.5 kW | |
| max. operating temperature | 50 °C | |
| Degree of protection (IP) | IP20/IP40 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85371098 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
