ESD0521Z | Diotec
SMD ESD protection diode, bidirectional, 100 W, 5 V, 0603, Diotec ESD0521Z
Order No.: 70S0064
MPN:
ESD0521Z
Unit Price (€ / pc.)
0.0345 € *
Standard delivery time from the manufacturer is: 4 Weeks
ESD Protection Diode in SMD, ESD0521Z, Diotec
Features
- Low junction capacitance
- Low leakage current
- Miniature case outline outline
- Compliant to RoHS
Applications
- ESD protection
- Data line and I/O port protection
- Commercial grade
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | 0603 | |
| max. operating temperature | 150 °C | |
| Assembly | SMD | |
| min. operating temperature | -50 °C | |
| Version | bidirectional | |
| Rated blocking voltage | 5 V | |
| Breakdown voltage | 11 V | |
| Pulse power loss | 100 W |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85411000 |
| MSL | MSL 1 |
| Original Packaging | Reel with 10,000 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
