DI5315-02F | Diotec
SMD ESD protection diode, unidirectional, 60 W, 5 V, DFN1006-3, Diotec DI5315-02F
Order No.: 70S0058
MPN:
DI5315-02F
Unit Price (€ / pc.)
0.0754 € *
Standard delivery time from the manufacturer is: 4 Weeks
ESD Protection Diodes in SMD, DI5315-02F, Diotec
Features
- Very low junction capacitance
- Protects two channels
- Low leakage current
- Miniature case outline outline
- Compliant to RoHS
Applications
- ESD protection
- High speed data line and I/O port protection
- HDMI Handheld devices
- Commercial / Industrual grade
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | DFN1006-3 | |
| Number of diodes | 1 | |
| max. operating temperature | 150 °C | |
| Assembly | SMD | |
| min. operating temperature | -50 °C | |
| Version | unidirectional | |
| Rated blocking voltage | 5 V | |
| Breakdown voltage | 9 V | |
| Pulse power loss | 60 W |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85411000 |
| MSL | MSL 1 |
| Original Packaging | Reel with 10,000 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
