DI017P03PT2-AQ | Diotec

Name: Diotec P/P channel MOSFET, -30 V, -17 A, PowerQFN 3x3-Dual, DI017P03PT2-AQ
Brand: Diotec
SKU: 09S4582
Availability: InStock

Diotec P/P channel MOSFET, -30 V, -17 A, PowerQFN 3x3-Dual, DI017P03PT2-AQ

Order No.: 09S4582

MPN:

DI017P03PT2-AQ

Series: DI

Image may differ

Key Specification:

Version P/P channel

max. Voltage -30 V

Max. current -17 A

drain-source on resistance RDS (on) max @VGS=4,5V 50 mΩ

drain-source on resistance RDS (on) max @VGS=10V 30 mΩ

Unit Price (€ / pc.)

0.4165 € *

Standard delivery time from the manufacturer is: 4 Weeks

Total Price:

2,082.50 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Features

Applications

Technical specifications

Filter	Property	Value
	Gate Charge Qg @10V (nC)	1.98x10<sup>-8</sup> C
	max. operating temperature	175 °C
	min. operating temperature	-55 °C
	Assembly	SMD
	max. Voltage	-30 V
	drain-source on resistance RDS (on) max @VGS=4,5V	50 mΩ
	Max. current	-17 A
	Power loss	13.1 W
	Version	P/P channel
	Enclosure	PowerQFN 3x3-Dual
	drain-source on resistance RDS (on) max @VGS=10V	30 mΩ
