S250 | Diotec
Diotec SMD bridge rectifier, 250 V, 600 V (RRM), 800 mA, mini DIP, S250
Discontinued
Unit Price (€ / pc.)
0.0714 € *
Available: 847 pcs.
Diode bridge rectifier, S250, DIOTEC
Features
- Four diodes in bridge configuration
- Slim profile package
- Low forward voltage drop
- UL recognized
- Compliant to RoHS, REACH and conflict minerals
Applications
- 50/60 Hz mains rectification
- Power supplies
- Commercial grade
Technical specifications
| Version | 1-phase | |
| Assembly | SMD | |
| Enclosure | mini DIP | |
| Input voltage | 250 V | |
| Rated current | 800 mA | |
| Voltage V RRM (peak reverse voltage) | 600 V | |
| min. operating temperature | -50 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Customs tariff number | 85411000 |
| Country of origin | SI |
| Original Packaging | Reel with 5,000 pieces |
Compliance
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
